Single Panel Operable Walls

Single Panel Operable Walls provide the ultimate in versatility and flexibility. Additionally, This system is allowing for capabilities such as multiple room setups and changes in the location of pass doors and work surfaces. Furthermore, Canuck Door Systems offers several types of Single Panel Operable Walls.

Get Quote

FEATURES

The Panel Operable Walls have many amazing features. Firstly, they have the most flexibility as the panels can turn corners. Secondly, they are supported from above, with no weight on the floor. Thirdly, each panel is individual, with two trolleys. Furthermore, the panels are stacked to one side of the track, or in a remote location. Additionally, the panels can be stored in a pocket, with or without pocket doors.

TYPES OF SINGLE PANEL OPERABLE WALLS

TYPE “A” PANEL CONSTRUCTION
  • Least expensive
  • Paired or Single panels with sweep seal only
  • Welded steel frame. Also, they have a bonded standard MDF / PB face
  • STC 49 to ASTM E90-90
  • Maximum height – 10′ or 3050mm. Also, the maximum width is 54″ or 1370mm, furthermore, the weight is 7 lbs. / sq. ft., or 29 kg. / sq. mtr.
TYPE “B” PANEL CONSTRUCTION
  • Medium cost
  • Available for all operations
  • Welded steel frame. Also, they have a bolted MDF / PB face
  • STC 49 to ASTM E90-90
  • Maximum width – 54″ or 1370mm. Additionally, there is no maximum height. Also, the weight is 8 lbs. / sq. ft., or 39 kg. / sq. meter.
TYPE “C” PANEL CONSTRUCTION
  • Moderate cost
  • Available for all operations
  • Welded steel frame. Also, they have a 21-26 gauge steel liner and bolted MDF / PB face.
  • STC 52 to ASTM E90-90
  • Maximum width – 54″ or 1370mm. Also, there is no maximum height. Moreover, the weight is 10 lbs. / sq. ft., or 49 kg. / sq. meter.
TYPE “D” PANEL CONSTRUCTION
  • Most expensive
  • Available for all operations
  • Welded steel frame, 21-26 gauge steel face
  • STC 54 to ASTM E90-90
  • Maximum width – 48″ or 1235mm. In addition, they have no maximum height. Also, the weight is 10 lbs. / sq. ft., or 49 kg. / sq. meter.

SINGLE PANEL OPERABLE WALLS  INSTALLATION

Canuck Door Systems is a dealer of the AOW, the leading manufacturer of operable walls in North America.

We install operable walls in  Toronto, Mississauga, Brampton, Vaughan, Richmond Hill, Markham, Hamilton, Burlington, Oakville, Pickering, Ajax, Oshawa, Aurora, Newmarket and throughout South Ontario is no exception.

Canuck Doors Systems also installs Paired Panel Operable Walls, Electric Operable Walls, Electric Gym Operable Walls, and Single Panel Floor Supported Operable Walls.
